8 inch color LCDdisplay,touch screen operation.

Visualization of panel and visualization of panel data.

Full closed design of optical path system and long term maintenance free.

Automatic switch door,automatic sampling test,no manual opening.

Center location,accurate data,good stability and good repeatability.

The filter wheel can carry 10 filters and replace them outside the instrument.

End point method, kinetic method,inhibition rate,single/dual wavelength measurement.

It can detect foot and mouth disease,small ruminants,pseudorabies,blue ear and swine fever.

Main Parameters

Lamp：DC12V 22W Tungsten halogen lamp

Optical path:8 channel vertical light path system

Wavelength range：400-1000nm(Selection:340-1100nm)

Filter:Default configuration 405、450、492、630nm, Can be installed up to 10 filters.

Reading range:0-4.000Abs

Linear range:0-3.000Abs

Resolution: 0.001Abs

Accuracy:≤±0.01Abs

Stability:≤±0.003Abs

Repeatability:≤0.3%

Incubation function:room temperature+4℃~50℃，accuracy 37℃±0.5℃（Selection）

Vibration plate :Three kinds of linear vibration plate function, Adjustable 0-255 seconds

Display: 8 inch color LCD screen, display the entire board information, touch screen operation.

Software: Professional software, Can store 200 groups  program, 100000 sample results,More than10 kinds of curve fitting equation.

Power input:AC100-240V  50-60Hz

Weight:11Kg

Size:433mm(L)*320mm(W)*308mm(H)
